Cranking Rating: 10 sec. 2,750 Amps
Cranking Rating: 1 min. 1,150Amps
Maximum Voltage Rating : 32 Volts DC
Terminal Stud Size: 1/2 (M12)
Intermittent Rating: 5 min. 700 Amps
Continuous Rating : 500 Amps
Terminal Stud Torque: 220 in-lb (24.86 N•m)
Mounting Holes : Accept 1/4 (M6) Screw
Cable Size to Meet Ratings : 4/0 AWG (120mm²)
Terminal Stud Torque : 220 in-lb (24.86 N•m) max.
Cable Clearance For 4/0 AWG Cables: 1.10 (27.9mm)
Agency Standards : UL Listed – UL 1107 Electric Power Switch Meets UL 1500 and SAE J1171 external ignition protection requirements
Cable Quantity to Meet Ratings : Two Cables / Terminal
Weight Lb (Kg) : 1.25 (0.57)
